ANV
	Cables with thick isolation
	Conductor		Insulation Thickness		Outer Diameter		Max. resistance	Weight
	Cross Section	No. & Diameter	Nominal	Min.	min.	max.	at 20 °C	approx.
	(mm²)	(mm)	(mm)	(mm)	(mm)	(mm)	(mΩ/m)	(kg/km)
	0.5	16x0.19	0.6	0.44	1.8	2.3	37.1	8
	0.75	24x0.19	0.6	0.44	2.1	2.5	24.7	12
	1	32x0.19	0.6	0.44	2.3	2.7	18.5	15
	1.5	27x0.25	0.6	0.44	2.6	3.0	12.7	20
	2.5	45x0.25	0.7	0.53	3.2	3.6	7.6	32
	4	56x0.29	0.8	0.62	3.9	4.4	4.71	51
	6	84x0.29	0.8	0.62	4.5	5.0	3.14	75
	10	80x0.39	1.0	0.80	5.7	6.5	1.82	127
	16	126x0.39	1.0	0.80	7.2	8.3	1.16	185
	25	196x0.39	1.3	1.07	9.6	10.4	0.743	300
	35	276x0.39	1.3	1.07	10.9	11.6	0.527	440
	50	396x0.39	1.5	1.25	11.3	13.5	0.368	590
	70	360x0.49	1.5	1.25	15.0	15.5	0.259	830
	95	475x0.49	1.6	1.34	17.5	18.0	0.196	1100
	120	608x0.49	1.6	1.34	19.2	19.7	0.153	1320
	Cables with thin isolation
	Conductor		Insulation Thickness		Outer Diameter		Max. resistance	Weight
	Cross Section	No. & Diameter	Nominal	Min.	min.	max.	at 20 °C	approx.
	(mm²)	(mm)	(mm)	(mm)	(mm)	(mm)	(mΩ/m)	(kg/km)
	0.22	7x0.20	0.30	0.24	1.1	1.3	84.8	3.3
	0.35	12x0.20	0.30	0.24	1.2	1.5	54.4	4.5
	0.5	16x0.19	0.35	0.28	1.6	1.9	37.1	7.3
	0.75	24x0.19	0.35	0.28	1.7	2.1	24.7	9.6
	1	32x0.19	0.35	0.28	1.9	2.3	18.5	12
	1.5	27x0.25	0.35	0.28	2.2	2.6	12.7	18
	2	28x0.29	0.35	0.28	2.4	2.8	9.42	23
	2.5	45x0.25	0.35	0.28	2.6	3.0	7.6	28
	3	44x0.29	0.40	0.32	3.0	3.4	6	34
	4	56x0.29	0.40	0.32	3.3	3.8	4.71	44
	5	70x0.29	0.45	0.36	3.7	4.2	3.94	56
	6	84x0.29	0.45	0.36	3.9	4.5	3.14	64
	10	80x0.39	0.60	0.48	5.2	6.0	1.82	108
	16	126x0.39	0.65	0.52	6.9	7.9	1.16	179
	25	196x0.39	0.65	0.52	8.5	9.4	0.757	280
